LPF11 Angle Seat Valve

LPF11 Angle Seat Valve

Pneumatic Angle Seat Valve, Electric Control Angle Seat Valve, Pneumatic Control Angle Seat Valve

LPF11 Pneumatic Angle Seat Valve PDF catalogues

Design Feature

  1. Applicable to Any inert gases, corrosive fluids, gases
  2. Long life, high sensitivity
  3. Can rotate 360 degrees
  4. Good flow characteristics

Parameter

Actuator Pneumatic, Handle
Control On-off, Modulating, Inteligent
DN 10~100mm
Pressure 0.3~0.5Mpa
Temperature -10~70°C
Connection Flange, Thread, Weld, Clamp
Structure 1-piece Type
Body Material SS316L, SS316, SS304
Ball Material SS316L, SS316, SS304
Sealing Material PTFE, TFM, EK, BODY, STL
Medium Gas, Water and Oil, etc
Option Proximity Switch, Positioner, Solenoid Valve, Manual Override for Stroke Actuator
